Metal Ministry Inc. is a leading Exporter & Supplier of Incoloy Alloy 800/800H/800HT. Incoloy 800, 800H, and 800HT are nickel-press chromium alloy with great quality and incredible resistance to oxidation and carburization in high-temperature presentation. These nickel steel Alloy are indistinguishable aside from the more elevated amount of carbon in compound 800H, and the expansion of up to 1.20 percent aluminum and titanium in alloy 800HT. Incoloy 800 was the first of these combinations and it was somewhat adjusted into Incoloy 800H. This adjustment was to control carbon (.05-.10%) and grain size to advance anxiety crack properties. Incoloy 800HT has assist alterations to the consolidated titanium and aluminum levels (.85-1.20%) to guarantee ideal high temperature properties.
The nickel combination is double guaranteed (800H/HT) and joins the properties of both structures. Incoloy 800H/HT amalgam was planned for high temperature auxiliary applications. The nickel content makes the compounds exceedingly impervious to both chloride stretch consumption breaking and to embrittlement from precipitation of sigma stage. The general corrosion resistance is superb. In the arrangement toughened condition, compounds 800H and 800HT have unrivaled crawl and stress crack properties. Today, most providers, including Mega Mex, just convey the double ensured 800H/HT compound. We further supply these Incoloy Alloy 800/800H/800HT in wide ranges at minimum price.
Metal Ministry Inc. Exports & Supply's Incoloy Alloy 800/800H/800HT Round bars, Incoloy Alloy 800/800H/800HT Hex bars, Incoloy Alloy 800/800H/800HT Forged Bars, Incoloy Alloy 800/800H/800HT Strips, Incoloy Alloy 800/800H/800HT Sheets, Incoloy Alloy 800/800H/800HT Plates, Incoloy Alloy 800/800H/800HT Seamless Pipes, Incoloy Alloy 800/800H/800HT Welded Pipes, Incoloy Alloy 800/800H/800HT ERW Pipes, Incoloy Alloy 800/800H/800HT Large Diameter Pipes, Incoloy Alloy 800/800H/800HT ( All types of flanges), Incoloy Alloy 800/800H/800HT Fasteners, Incoloy Alloy 800/800H/800HT Nuts/Bolts/Washers, Incoloy Alloy 800/800H/800HT Forged Fittings, Incoloy Alloy 800/800H/800HT Buttweld Fittings, Incoloy Alloy 800/800H/800HT Olets, Incoloy Alloy 800/800H/800HT Weldolets, Incoloy Alloy 800/800H/800HT Sockolets, Incoloy Alloy 800/800H/800HT Instrumentation Fittings.
Specification of Incoloy Alloy 800/800H/800HT
| Rod, Bar and Forging Stock | ASTM B 408 & ASME SB 408 (Rod & Bar), ASTM B 564 & ASME SB 564 (Forgings), ASME Code Case 1325 (All Product Forms), ASME Code Case 1949 (Forgings), SAE/AMS 5766 (Rod & Bar), ISO 9723 (Rod & Bar), ISO 9724 (Wire), ISO 9725 (Forgings), BS 3076NA15 (Rod & Bar), BS 3075NA15 (Wire), VdTÜV 412 (All Products) |
|---|---|
| Plate, Sheet and Strip | ASTM A 240/A 480 & ASME SA 240/SA 480 (Plate, Sheet, and Strip), ASTM B 409/B 906 & ASME SB 409/SB 906 (Plate, Sheet, and Strip), ASME Code Case 1325 (All Product Forms), ASME Code Case 2339 (Plate), SAE/AMS 5871 (Plate, Sheet, and Strip), BS 3072NA15 (Plate & Sheet), BS 3073NA15 (Strip), VdTÜV 412 (All Products), ISO 6208 (plate, sheet and strip) |
| Pipe and Tube | ASTM B 163 & ASME SB 163 (Seamless Condenser & Heat Exchanger Tubes), ASTM B 407/B 829 & ASME SB 407/SB 829 (Seamless Pipe & Tubes), ASTM B 514/B 775 & ASME SB 514/SB 775 (Welded Pipe), ASTM B 515/B 751 & ASME SB 515/SB 751(Welded Tubes), ASME Code Case 1325 (All Product Forms), ASME N-20 (Cold Worked Seamless Condenser and Heat Exchanger Tubes for Nuclear Service), BS 3074NA15 (Seamless Pipe & Tubes), VdTÜV 412 (All Products), ISO 6207 (Seamless Tubing) |
| Other | ASTM B 366 & ASME SB 366 (Fittings) |
Chemical Composition of Incoloy Alloy 800
| Ni | Cr | Fe | C | Al | Ti | Al+Ti |
|---|---|---|---|---|---|---|
| 30.0-35.0 | 19.0-23.0 | 39.5 min | .10 max | .15-.60 | .15-.60 | .30-1.20 |
Chemical Composition of Incoloy Alloy 800H
| Ni | Cr | Fe | C | Al | Ti | Al+Ti |
|---|---|---|---|---|---|---|
| 30.0-35.0 | 19.0-23.0 | 39.5 min | .05-.10 | .15-.60 | .15-.60 | .30-1.20 |
Chemical Composition of Incoloy Alloy 800HT
| Ni | Cr | Fe | C | Al | Ti | Al+Ti |
|---|---|---|---|---|---|---|
| 30.0-35.0 | 19.0-23.0 | 39.5 min | .06-.10 | .25-.60 | .25-.60 | 0.85-1.2 |
Physical Properties of Incoloy Alloy 800/800H/800HT
| Properties | Description |
|---|---|
| Density | 7.94gm/cc |
| Melting Point | 1357-1385 oC |
| Specific Heat | 0.11 Btu/lb-oF |
| Curie Temperature | -175oC |
Metal Ministry Inc. are Suppliers & Exports of Incoloy Alloy 800/800H/800HT Round Bars, Pipes and Tubes, Pipe Fittings, Flanges & Fasteners to United States of America, Russia, United Kingdom, Kuwait, Qatar, Oman, UAE, Nigeria, Ethiosia, Egypt, Tanzania, Uganda, Algeria, Sudan, Morocco, Angola, Mozambique, Ghana, Cameroon, Cote D`lvoire, Niger, Burkina Faso, Mali, Malawi, Zambia, Senegal, Chad, Somalia, Zimbabwe, Guinea, Rwanda, Benin, Brundi, Tunisia, South Sudan, Togo, Sierra Leone, Libya, Congo, Liberia, Central African Republic, Mauritania, Eritrea, Namibia, Gambia, Botswana, Gabon, Lesotho, Guinea-Bissau, Mauritius, Eswatini, Djibouti, Comoros, Cabo Verde, Seychelles, Reunion, Western Sahara, Mayotte, Saint Helena, Afghanistan, Armenia, Azerbaijan, Bahrain, Bangladesh, Bhutan, Brunei, Cambodia, Cyprus, East Timor, Cyprus, Georgia, Indonesia, Iran, Iraq, Israel, Japan, Kazakhstan, Jordan, Kyrgyzstan, Lebanon, Malaysia, Maldives, Mongolia, Myanmar, Nepal, North Korea, Palestine, Philippines, Saudi Arabia, Singapore, South Korea, Sri Lanka, Syria, Tajikistan, Thailand, Turkey, Taiwan, Uzbekistan, Vietnam, Yemen, Albania, Andorra, Austria, Belarus, Belgium, Bosnia & Herzegovina, Bulgaria, Croatia, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Liechtenstein, Lithuania, Luxembourg, Malta, Moldova, Monaco, Montenegro, Norway, Netherlands, Poland, Portugal, Romania, Russia, San Marino, Serbia, Slovakia, Slovenia, Spain, Sweden, Switzerland, Ukraine, Vatican City, Antigua & Barbuda, Anguilla, The Bahamas, Barbados, British Virgin Island, Canada, Cayman Island, Costa Rica, Cuba, Dominica, Greenland, Haiti, Jamaica, Martinique, Mexico, Navassa Island, Panama, Puerto Rico, Saint Lucia, Trinidad & Tobago, Argentina, Brazil, Bolivia, Chile, Ecuador, Colombia, Guyana, Paraguay, Peru, Uruguay, Venezuela, Australia, Fiji, Marshall Island, New Zealand, Papua New Guinea, Samoa, Solomon Islands & Tuvalu.
For any enquiries related to Incoloy Alloy 800/800H/800HT Round Bars, Pipes and Tubes, Pipe Fittings, Flanges & Fasteners, kindly contact us on :-
